✅ Fully independent R&D industrial control host ✅ 2MP high-definition imaging camera ✅ 2K high resolution display for clear vein view ✅ CE medical grade certification
✅ Real-time algorithm for optimal contrast and sharpness
✅ High-brightness cold LED preventing tissue burns
Complies with the electrical safety requirements of GB 9706.1-2007.
2
Conforms to the electromagnetic compatibility requirements of YY 0505-2012.
3
Under specific magnification, the lens working distance shall cover no less than 200 mm to 300 mm.
5
Working distance ≥ 100 mm at 3× magnification.
6
Working distance ≥ 15 mm at 18× magnification.
7
Depth of field ≥ 120 mm at 6× magnification; depth of field ≥ 5 mm at 18× magnification.
8
Optical zoom: 1–28×, linear correlation coefficient R of magnification ≥ 0.95; electronic magnification up to 280×.
9
Illuminance is adjustable. Under maximum illuminance, the output beam illuminance of the instrument shall be ≥ 1600 Lx within the working distance of 200–300 mm.
10
White light color temperature: 4000 K ~ 5500 K.
11
The diameter of illuminated spot ≥ 60 mm at working distance of 200–300 mm.
12
Illuminance uniformity ≤ 110%.
13
Temperature rise at the center of irradiated surface ≤ 11 °C when working distance L = 200 mm.
Maximum color rendering error ≤ 30 NBS, average color rendering error ≤ 20 NBS; average camera saturation value: 95% ~ 120%.
16
Image geometric distortion ≤ 3%.
17
2-megapixel color CCD camera.
Graphic introduction
Introduction
Digital Electronic Colposcope Real Clinical Shot of Cervical Lesion Screening
This clinical image is truly shot by our HD digital colposcope. The 2MP CCD camera and high color restoration system clearly present cervical mucosal lesions, subtle blood vessels and tissue exudate without geometric distortion. It provides clear, true lesion details to assist gynecologists in accurate cervical disease diagnosis and cervical cancer screening.
✅ Ultra-high definition capture of cervical subtle lesions ✅ True color restoration of cervical mucosal tissue features ✅ Distortion-free imaging to avoid misdiagnosis risk ✅ Clear display of tiny blood vessels & tissue exudate ✅ Stable real-time dynamic clinical observation
Clear Cervical Lesion Display Effect Taken by Electronic Colposcope
This real clinical picture is captured by our HD digital electronic colposcope. The 2MP CCD camera and 2K display restore clear cervical mucosal texture, tiny blood vessels and subtle cervical lesion features without distortion, supporting accurate gynecological cervical cancer screening and diagnosis for
✅ 2MP color CCD HD camera & 2K high resolution display ✅ 1–28× optical zoom, max 280× electronic magnification ✅ High color reduction, real cervical lesion detail presentation ✅ Multi-language system including Arabic for Middle East clinics ✅ Low geometric distortion, stable long-time clinical imaging ✅ Adjustable illuminance with over-temperature safety protection
Advanced Visualization for Precision Screening
This real clinical picture is captured by our digital electronic colposcope under green light mode
✅ Auto-Optimization: Enhances sharpness and contrast
FAQs
Q1:What's the camera and display configuration of the colposcope?
It is equipped with a 2MP color CCD HD camera and 2K monitor, supporting 1920×1080 high-definition image output, clear cervical tissue observation.
Q2: What zoom range does this colposcope support?
A: Optical zoom ranges from 1× to 28×, linear correlation coefficient R≥0.95; max electronic magnification reaches 280×, with adjustable depth of field for different examination distances.
Q3: What's the working distance and illumination parameter?
A: Standard working distance: 200–300mm, illuminance ≥1600Lx, white light color temperature 4000–5500K, with overheating protection to avoid patient discomfort.
Q4: Can you offer OEM & wholesale service?
A: We support full independent R&D customized OEM service, including brand logo, software language, trolley bracket and packaging customization, competitive bulk wholesale price for medical distributors.
Q5: What after-sales support do you provide?
A: 1-year global warranty, online technical operation training, spare parts supply, remote software debugging and professional clinical operation guidance.
Q6: What's the minimum order quantity?
A: MOQ is 1 unit for sample testing; large quantity orders for hospitals and distributors get extra discounted price and priority delivery.
