0.12MP HD Electronic Colposcope

5 0 Reviews

✅ 0.12MP color CCD camera with steady real-time clinical image output
✅ Stepless adjustable magnification to observe cervical mucosal lesions
✅ Excellent color rendering for true reproduction of tissue morphology
✅ Self developed system supporting global clinic usage
✅ Adjustable uniform LED lighting for consistent examination view
✅ Simple ergonomic operation, ideal for grassroots gynecology screening

Price: $ 1500 / 台

Discount Price: $ 960 / 台

Availability:

Quantity:



Buy Now Add to Cart

Model:
BC-120H
Brand:
DERUK
Code:
V-2600200

Colposcope Video Colposcope منظار مهبلي رقمي منظار المهبل جهاز كشف الأوردة المحمول بالأشعة تحت الحمراء кольпоскоп для гинекологии Digital Colposcope портативный кольпоскоп Cervical Cancer Screening Colposcope Gynecology Colposcope

Product Description

Digital Electronic Colposcope is widely applied in gynecological routine examination, cervical lesion screening and follow-up observation.
This cost-effective model integrates a 0.12MP color CCD camera to capture clear real-time images of cervical tissue.
Adjustable magnification and excellent color restoration help clinicians identify subtle surface lesions effectively.
Equipped with dimmable LED light source, the device offers soft and uniform illumination without glare.
The multi-language system facilitates operation for global users.
Ergonomic design enables easy daily operation, while stable long-term working performance lowers maintenance costs.
It is widely favored by primary medical centers, outpatient clinics and medical examination centers for daily cervical screening work.

Technical Specifications

No	Technical Specifications
1	Complies with the electrical safety requirements of GB 9706.1-2007.
2	Conforms to the electromagnetic compatibility requirements of YY 0505-2012.
3	Under specific magnification, the lens working distance shall cover no less than 200 mm to 300 mm.
5	Working distance ≥ 100 mm at 3× magnification.
6	Working distance ≥ 15 mm at 18× magnification.
7	Depth of field ≥ 120 mm at 6× magnification; depth of field ≥ 5 mm at 18× magnification.
8	Optical zoom: 1–36×, linear correlation coefficient R of magnification ≥ 0.95; electronic magnification up to 280×.
9	Illuminance is adjustable. Under maximum illuminance, the output beam illuminance of the instrument shall be ≥ 1600 Lx within the working distance of 200–300 mm.
10	White light color temperature: 4000 K ~ 5500 K.
11	The diameter of illuminated spot ≥ 60 mm at working distance of 200–300 mm.
12	Illuminance uniformity ≤ 110%.
13	Temperature rise at the center of irradiated surface ≤ 11 °C when working distance L = 200 mm.
14	System resolution ≥ 550 TVL, spatial resolution ≥ 10 lp/mm, image resolution ≥*10241200**
15	Maximum color rendering error ≤ 30 NBS, average color rendering error ≤ 20 NBS; average camera saturation value: 95% ~ 120%.
16	Image geometric distortion ≤ 3%.
17	2-megapixel color CCD camera.

Graphic introduction

Introduction

Digital Electronic Colposcope Real Clinical Shot of Cervical Lesion Screening

This clinical image is truly shot by our HD digital colposcope. The 2MP CCD camera and high color restoration system clearly present cervical mucosal lesions, subtle blood vessels and tissue exudate without geometric distortion. It provides clear, true lesion details to assist gynecologists in accurate cervical disease diagnosis and cervical cancer screening.

✅ Ultra-high definition capture of cervical subtle lesions
✅ True color restoration of cervical mucosal tissue features
✅ Distortion-free imaging to avoid misdiagnosis risk
✅ Clear display of tiny blood vessels & tissue exudate
✅ Stable real-time dynamic clinical observation
Clear Cervical Lesion Display Effect Taken by Electronic Colposcope

This real clinical picture is captured by our HD digital electronic colposcope. The 120MP CCD camera and 1080P display restore clear cervical mucosal texture, tiny blood vessels and subtle cervical lesion features without distortion, supporting accurate gynecological cervical cancer screening and diagnosis for

✅ 120MP color CCD HD camera & 1080 high resolution display
✅ 1–36× optical zoom, max 360× electronic magnification
✅ High color reduction, real cervical lesion detail presentation
✅ Multi-language system including Arabic for Middle East clinics
✅ Low geometric distortion, stable long-time clinical imaging
✅ Adjustable illuminance with over-temperature safety protection
120MP Ultra-HD Colposcope with Advanced Green Filter

Featuring an ultra-HD 120 Megapixel imaging system and an advanced vascular-enhancing green filter, it captures microscopic tissue details and subtle capillary structures with absolute clarity. Seamlessly blending high-resolution magnification with intelligent autofocus, it provides clinicians with the ultimate visual confidence required for early cervical cancer screenings.

✅ Advanced Green Filter: Enhances contrast to clearly reveal subtle vascular patterns.

✅ Lossless Digital Zoom: Magnifies intricate tissue details without losing sharpness.

✅ True Color Visualization: Captures natural tissue changes and acetowhite areas accurately.

✅ Smart Fast Autofocus: Delivers rapid, sharp images to boost examination efficiency.

✅ Pro Shadowless LED: Combines uniform illumination with green mode for superior contrast.

FAQs

Q1:What's the camera and display configuration of the colposcope?

It is equipped with a 2MP color CCD HD camera and 2K monitor, supporting 1920×1080 high-definition image output, clear cervical tissue observation.
Q2: What zoom range does this colposcope support?

A: Optical zoom ranges from 1× to 28×, linear correlation coefficient R≥0.95; max electronic magnification reaches 280×, with adjustable depth of field for different examination distances.
Q3: What's the working distance and illumination parameter?

A: Standard working distance: 200–300mm, illuminance ≥1600Lx, white light color temperature 4000–5500K, with overheating protection to avoid patient discomfort.
Q4: Can you offer OEM & wholesale service?

A: We support full independent R&D customized OEM service, including brand logo, software language, trolley bracket and packaging customization, competitive bulk wholesale price for medical distributors.
Q5: What after-sales support do you provide?

A: 1-year global warranty, online technical operation training, spare parts supply, remote software debugging and professional clinical operation guidance.
Q6: What's the minimum order quantity?

A: MOQ is 1 unit for sample testing; large quantity orders for hospitals and distributors get extra discounted price and priority delivery.

Exhibition Information

展会图
